Vulcan K20EL 20 Gallon Stationary 2/3 Steam Jacketed Electric Kettle
Vulcan K20EL 20 Gallon Stationary 2/3 Steam Jacketed Electric Kettle
Availability: In Stock
Vulcan K20EL 20 Gallon Stationary 2/3 Steam Jacketed Electric Kettle
Vulcan
Add to Wish List Compare this Product
Product Code: K20EL
$24,458.00
Email us to place your order and you will get a discount up to 10% off.
Ask About This Product
Description

The K20EL is a Staionary Gas Kettle from Vulcan that runs on Electricity. This floor mounted kettle is constructed of stainless steel, including a 316 series steel liner. The liner includes an ellipsoidal bottom. The compression draw-off valve features a perforated strainer. True working capacity is 20 gallons. The model is 2/3 jacketed. The tubular legs feature flanged feet. A draw-off valve features a perforated strainer The steam jacket contains treated and distilled water. There is a spring assist cover which includes a condensate ring and a drop-down lift handle.

The various controls include solid state temperature control (with warm, simmer, and boil settings), a vacuum/pressure gauge, and a pressure relief valve. A light, and eventually a shut-off, will occur when water is low. The controls, as well as the faucet bracket, are in an enclosure to protect from water. This unit is shipped 208v/60/1ph, but can be field converted to 208v/60/1ph, 240v/60/1ph, or 240v/60/3ph. It is UL listed, and meets NSF Standard #4. The compression draw-off valve features a perforated strainer.

Vulcan K20EL Features

  • Stationary Steam Kettle
  • Electric
  • Floor Model
  • Material: Stainless Steel
  • Capacity: 20 Gallons
  • Faucet Bracket
  • Heavy Bar Rim
  • 2/3 Jacket
  • Spring Assist Hinged Cover w/Condensate Ring
  • Draw-Off Valve w/Perforated Strainer
  • 316 Series Stainless Steel Liner
  • Low Water Light & Shut-Off
  • Water Resistant Controls
  • Tubular Legs
  • Flanged Feet
  • Embossed Gallon/Liter Markings
  • Electrical: 208v/60/3ph
  • Field Convertible to Single Phase and/or 240 Volt
  • UL Listed

Overall Dimensions:
Height: 31 7/8"
Width: 32 1/2"
Depth: 23"

View all Description
  • Electric
  • Floor Model
  • Material: Stainless Steel
  • Capacity: 20 Gallons
  • Faucet Bracket
  • Heavy Bar Rim
  • 2/3 Jacket
  • Spring Assist Hinged Cover w/Condensate Ring
  • Draw-Off Valve w/Perforated Strainer
  • 316 Series Stainless Steel Liner
  • Low Water Light & Shut-Off
  • Water Resistant Controls
  • Tubular Legs
  • Flanged Feet
  • Embossed Gallon/Liter Markings
Categories: Vulcan Electric Steam Kettles
This item was made in the United States of America.
